Used Atlas approx 21 sq. ft. C-276 horizontal shell and tube heat exchange
DSM02002-0806

Used Atlas approx 21 sq. ft. C-276 horizontal shell and tube heat exchange

Used Atlas approx 21 sq. ft. C-276 horizontal shell and tube heat exchange

Used Atlas approx 21 sq. ft. C-276 horizontal shell and tube heat exchange

Description:
Used Atlas approximately 21 sq. ft. horizontal shell and tube heat exchanger.  5 9/16" diameter X 7'-9" overall length.  Carbon steel shell rated 100 PSI @ -20 to 200 degrees F.  Hastelloy C-276 tubes rated 75/FV @ -20 to 300 degrees F.  Hastelloy welded tubsheets are 5.2945" diameter X 3/4" thick.  Contains (18) 3/4"OD tubes made of 18 GA hastelloy.  NB# 6816. Serial # 8164.  Built 1992.  Equipped with (12) 1/8" carbon steel baffles.  Mounted on carbon steel feet giving 5 degree incline. FOB: Wilmington, NC

Location:  Stock located in Wilmington, NC
